Board-and-Batten Siding Reborn

With a bit of thoughtful design, this simple style of siding can create elegant exteriors.

By Debra Silber
  • X
  • facebook
  • linkedin
  • pinterest
  • email
  • add to favorites Log in or Sign up to save your favorite articles

There was a time when I despised board-and-batten siding. I suspect that’s because growing up in the suburbs of Long Island, it was among several types of vertical siding I saw applied to raised ranches in an apparent attempt to draw attention away from their awkward horizontal proportions. It worked–sometimes. But it took me a long time to stop blaming the siding for the sins of the style.

I’m seeing a lot more board-and-batten these days, but this time around, I’m loving it. Not only have I come to appreciate its honest, rural roots, but I’m seeing a new generation of builders and architects applying this form of siding to homes of all kinds of styles in ways that work.

If you need a visual, board-and-batten siding consists of wide boards spaced slightly apart, with the spaces covered by thinner strips of wood (the battens). A variant, reverse board-and-batten, places the thin strips behind the wider boards. Either way, the pattern created by the alternating boards adds a distinctive vertical element to the architecture.

Because the battens are intended to be nailed to the studs, the spacing of a home’s framing can influence the board-and-batten pattern. Architect Matthew Swett, whose project is among those featured here, points out that this can trip up the aesthetics. Spacing battens 16 in. apart (the customary distance between studs) looks a bit wide to him. He believes that battens look better placed about 12 in. apart, but that method requires blocking or other, less optimal workarounds.

Commonly associated with rural farm buildings, board-and-batten is a natural for farmhouses and backyard sheds (we’ve even seen it used recently on this charming doghouse). But maybe that’s also why it’s such a perfect foil for more contemporary designs. Judging from what we see here at Fine Homebuilding, the simple siding is finding new favor among plenty of builders and architects as a thoroughly modern material.

What’s interesting is that it’s a revival of sorts. Utility sheds aside, board-and-batten on houses had a heyday back in the 19th century, before the Civil War. At the time, enthusiasts such as architect Andrew Jackson Downing championed the vertical battens as an expression of the framing beneath it. Board-and-batten was a popular choice for Carpenter-Gothic homes, and you could argue that it enjoyed new celebrity in the “Stick” style of late Victorian times. Inside the house, we can see the pattern mimicked in the vertical flat-panel wainscot that’s typical of Craftsman homes–another style enjoying renewed popularity today.

Some more great examples of board-and-batten done well

board-and-batten siding ranch house
Tied for third place in our 2014 Readers’ Choice Awards, this sprawling contemporary farmhouse designed by architect Coby Linton is actually a remodel of a drab ranch. The striking verticality of the board-and-batten siding can’t be missed here.
rigid foam between its traditional-looking board-and-batten sidin
This Passive House built on California’s Monterey Peninsula incorporates rigid foam between its traditional-looking board-and-batten siding and its high-performance walls. Designed by architect Justin Pauly, it was designated best new home in our 2013 Houses Awards.
fiber-cement panels cover the front of this house
Board-and-batten is part of the vernacular in historic Coupeville, Wash., home to this family compound designed by architect Matthew Swett. The siding here consists of fiber-cement panels with cedar battens, a durable choice for its coastal location. We took closer look at this project in the article “Built on the Past, Designed for the Future.”



Fine Homebuilding Recommended Products

Fine Homebuilding receives a commission for items purchased through links on this site, including Amazon Associates and other affiliate advertising programs.

Graphic Guide to Frame Construction

Now in it’s 5th edition, Rob Thallon’s book for builders has been a go-to resource for decades. This book features clear graphics that will help you understand how nearly all American houses are — or should be — built.
Buy at Amazon

Pretty Good House

For anyone interested in a sensible and cost-effective approach to designing and building a home that is comfortable, healthy, efficient, and durable, this book is a fantastic starting point (really, it may be all you need!).
Buy at Amazon

A Field Guide to American Houses

If you want to plan, design, or remodel based on the vast tradition of American architectural styles you first have to understand their history, geography, architectural significance, and relationship to one another. This book can help with that.
Buy at Amazon
Previous: What to Consider When Choosing Black Siding Next: Wood Siding: Burnt, Brushed, and Burnished

Guide

Siding & Exterior Trim

Chapter

Choosing Siding

Sign up for eletters today and get the latest how-to from Fine Homebuilding, plus special offers.

Signing you up...

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.
See all newsletters
See all newsletters

View Comments

  1. HobbesJourney | Feb 23, 2015 04:45pm | #1

    The author notes, "Because the battens are intended to be nailed to the studs, the spacing of a home's framing can influence the board-and-batten pattern. Architect Matthew Swett, whose project is among those featured here, points out that this can trip up the aesthetics. Spacing battens 16 in. apart (the customary distance between studs) looks a bit wide to him. He believes that battens look better placed about 12 in. apart, but that method requires blocking or other, less optimal workarounds."

    Wouldn't a simple workaround be to make fake boards and battens by using a plywood sheathing of some sort and nailing the boards to the sheathing rather than the studs? This would allow narrower spacing, bringing the look without worrying about the blocking.

  2. Giovannoli | Feb 23, 2015 08:51pm | #2

    Hobbes- We've sheathed houses with T-111 siding and added batts, but there are limitations to lengths; I've never seen longer than a ten foot sheet, so z-bar or other mechanical flashing is required at horizontal joints.
    Rather than reinvent the wheel and frame on non standard centers, one can run horizontal nailers every few feet over the studs, and nail accordingly. It is much stronger anyway, to not have continual joints on a 2x member. In shear wall sheathing, all vertical joints must break on a 3x stud.
    Anyway, after forty-two years of construction, I know that there are lots of different ways to skin a cat- not to mention a house.

  3. greg1951 | Mar 09, 2015 01:38pm | #3

    I refinished a 1925 Gardiner's cottage with "board" and batten by installing wood grained Hardi panels 4' X 10' on rain screen attached every 12". (I too like the 12 inch spacing.) I used roofing nails to attach the panels every 12". These go up very quickly. I painted the panels with acrylic (Benjamin-Moore) light grey paint to simulate weathered cedar. I then attached 1" X 2" (full dimension) cedar battens every 12" covering the nail rows and joins (4') on the panels. I atached the battens with 2" stainless steel brads. I used a full body stain in the same colour (Behr) on the battens. I think the effect is fabulous and has all the weathering benefits of cement based siding in our wet climate on the west coast. Sidney, Vancouver Island, British Columbia.

  4. DPEDWARDS | Mar 26, 2016 09:53pm | #4

    This house is beautiful and helped convince me that my husband was correct about covering our rustic house with board and batten siding. I would love to know what colors and brand of stain were used for this project.
