Snake Wire through Old Walls

Don’t let narrow wall cavities filled with plaster prevent you from running new wires.

By Charles Miller
  • X
  • facebook
  • linkedin
  • pinterest
  • email
  • add to favorites Log in or Sign up to save your favorite articles
Snake Wires Through Old Walls
Don’t let narrow wall cavities filled with plaster prevent you from running new wires in an old house.
Video Player is loading.
Current Time 0:00
/
Duration 1:31
Loaded: 0%
0:00
Stream Type LIVE
Remaining Time -1:31

1x
    • Chapters
    • descriptions off, selected
    • captions settings, opens captions settings dialog
    • captions off, selected
    • en (Main), selected

    This is a modal window.

    Beginning of dialog window. Escape will cancel and close the window.

    Text
    Background
    Window
    Font Size
    Text Edge Style
    Font Family

    End of dialog window.

    This is a modal window. This modal can be closed by pressing the Escape key or activating the close button.

    This is a modal window. This modal can be closed by pressing the Escape key or activating the close button.

    John Ross from Bethel, Conn., writes:

    The walls in my old colonial have only a 1-in. cavity between the two planes of lath, and much of that space is obstructed by plaster keys. When I wanted run new electrical wires, I couldn’t use a snake because it kept getting hung up on the globs of plaster inside the walls. To make a channel for the wire and to provide something to hook the wire to so I could pull it through the wall, I used a 3/16-in. by 1-1/2-in. piece of lath I purchased at the local home store. Now when I want to run wire, I locate were I want my wire to run, either from up top or down below. Then I shove the lath through the cavity, breaking the plaster keys as I go. Because of its shape, the lath keeps to a straight line. It sometimes takes some work to get the lath to an outlet or light-switch location, but once it’s there, I simply attach my wire to it and pull it back through the wall.

    Previous: Long Electrical Runs in Closed Walls Next: Creating a Wiring Trench
